48kg Gas Bottle Dimensions: Complete Buyer’s Guide (2026 Update)
Quick answer: A standard 48kg gas cylinder (commonly used for LPG, industrial gases, or N₂O) typically measures height 1190–1250 mm, diameter 305–320 mm, with a tare weight of 45–52 kg. However, dimensions vary by gas type, valve configuration, and regulatory standards. Whether you are sourcing for wholesale distribution, brand labeling, or OEM integration, knowing exact 48kg gas bottle dimensions is the first step to ensuring safe transport, storage, and compatibility with your filling systems. In this guide, we provide precise data from our factory, Zhuzhou XingYe Chemical, backed by 10+ years of experience manufacturing high-pressure steel cylinders for both industrial and food-grade applications.
Common Pain Points When Sourcing 48kg Gas Bottles
Import managers and wholesalers often encounter these challenges:
- Dimension mismatch – cylinders that don’t fit existing pallet racks, container corners, or filling equipment.
- Inconsistent weight tolerances – leading to incorrect freight calculations and customs clearance delays.
- Missing certifications – buyers in the US, EU, or Australia require DOT, TPED, or AS standards documentation.
- Supply chain uncertainty – waiting 60+ days for samples or not having OEM marking support.
Our factory addresses each pain point with documented specifications, flexible customization, and fast turnaround. Below we break down the exact measurements of our most popular 48kg gas bottle models.
Standard 48kg Gas Bottle Specifications (Zhuzhou XingYe Chemical)
| Parameter | Typical Range | Customization Available |
|---|---|---|
| Gas Capacity (Net Weight) | 48 kg (～120 lbs) | Yes (45–50 kg) |
| Outer Diameter | 318 mm ± 5 mm (12.5″) | OEM possible |
| Overall Height (including valve) | 1225 mm ± 10 mm (48.2″) | Yes (up to 1300 mm) |
| Tare Weight (empty cylinder) | 47.5 kg ± 2 kg | According to customer requirement |
| Working Pressure | 17.2–20.7 bar (250–300 psi) | Higher pressure for specific gases |
| Valve Connection | BSPP 1″ or CGA320 (US) | All major standards |
| Material | Seamless high-strength carbon steel (345R/4140) | Stainless steel option |
| Surface Finish | Epoxy powder paint – RAL color | Brand logo & colors |
| Standard Certifications | ISO 9001, CE, DOT SP, TPED, COA, MSDS | ECM, Food-grade (for N₂O) |
47 kg gas bottle dimensions 7kg gas bottle dimensions 5kg gas bottle dimensions
* Dimensions vary slightly depending on valve type and gas service – please confirm with our engineering team before placing a container order.
Why Source 48kg Gas Bottles from Zhuzhou XingYe Chemical?
⚙️ Powerful Factory & Customization
Founded in 2015 with a 15,000 m² production base, our facility employs 120+ skilled technicians. We offer complete OEM/ODM design: from dimension adjustments to valve adapter retrofits and pressure rating customization. Minimum Order Quantity (MOQ) starts at 500 units for standard colors, 100 units for custom specifications.
Lead Time: 20–30 days for standard samples; 35–45 days for bulk production (FOB Shanghai). Payment terms: T/T or L/C at sight.
✅ Quality Assurance & Certifications
Every cylinder undergoes hydrostatic testing, ultrasonic thickness measurement, and valve torque verification. Our certifications include ISO 9001:2015, CE (PED 2014/68/EU), DOT SP-2413, and, for food-grade applications, ECM and FDA-compliant internal coatings. We also provide a complete Certificate of Analysis (COA) and Material Safety Data Sheets (MSDS) with each shipment.
🚚 Logistics & After-Sales
We ship via 20′/40′ containers – a 20′ container holds approximately 200 units of 48kg cylinders (stacked in two layers). Packaging uses wooden pallets with shrink wrap to protect valve and surface. Standard warranty: 12 months from B/L date. We maintain stock in Tianjin and Shanghai for quick consolidation.
What Our Global Buyers Say
David Miller – Import Manager, Midwest Gases (USA)
“We previously struggled with dimensions that didn’t match our pallet racking. XingYe sent samples within 21 days with exact specs – now our logistic costs dropped by 8%.”
Sarah Chen – Brand Owner, Maple Wholesale (Canada)
“The OEM painting matched our brand colors perfectly. The 48kg gas bottle dimensions were consistent across the entire container. We’ve already placed three repeat orders.”
James O'Brien – Wholesaler, Pacific Cylinders (Australia)
“We needed AS 2469 certification – XingYe provided full test reports and the cylinders passed local inspection with no issues. The valve adapter for Australian standard was perfect.”
Ana Rodriguez – Sourcing Agent, GasNet Sourcing (Mexico)
“I appreciate that they didn’t use exaggerated marketing. The actual weight and dimensions were exactly as quoted. Fast response and reliable after-sales support.”
Tommy Lee – Purchasing Manager, HanGas (South Korea)
“For N₂O cream charger tanks we need strict food-grade interior. They provided COA and third-party test – the dimensions were within ±2 mm. Very professional.”
Frequently Asked Buyer Questions About 48kg Gas Bottle Dimensions
- What is the exact height of a 48kg LPG cylinder? Standard height is around 1225 mm including the valve. However, for N₂O or CO₂, the cylinder height may be slightly taller due to different gas densities. Always request a dimension drawing from our engineering team.
- Can I get a custom diameter to fit my existing racking system? Yes, we offer OEM development for diameter changes within the range of 300–340 mm, with corresponding wall thickness adjustments to maintain safety.
- What is the tare weight tolerance? Our manufacturing tolerance is ±2 kg for the 48kg gas bottle tare weight. This ensures accurate shipping weight calculation and customs compliance.
- Do you provide certification for US DOT transport? Yes, we can supply DOT-SP (Special Permit) cylinders. Please specify your target market when requesting a quote.
- How many 48kg cylinders fit in a 20ft container? Approximately 196–204 units depending on packaging and valve orientation. We can also provide CIF calculation based on your port.
Ready to Order 48kg Gas Bottles?
Contact our team today for a dimensional drawing, quotation, and sample lead time.
📞 Call / WhatsApp: +86 13787826843 or +86 19313298383
📧 Email: boss@happywhip.com | 🌐 Visit: whipways.com/contactus.html
We are happy to provide custom OEM solutions, free of charge initial design drafts, and technical support for your gas bottle dimensions project.
Understanding 48kg Gas Bottle Dimensions for Different Gases
A 48kg gas bottle is commonly used for LPG (propane/butane), nitrous oxide (N₂O), carbon dioxide (CO₂), and ethylene. While the gross weight remains around 48 kg, the physical dimensions may differ because of gas density and storage pressure.
For example, a 48kg LPG cylinder usually has a water capacity of 85–95 litres and works at 17 bar. In contrast, a 48kg N₂O cylinder requires a thicker wall due to higher pressure (up to 51 bar at 20°C), resulting in a slightly shorter but wider design to maintain safe stress levels. Our factory tailors the 48kg gas bottle dimensions to the exact service gas, and every design is verified with finite element analysis (FEA) before production.
Important Disclaimer: The dimensions and technical data provided in this article are typical values based on standard production runs. Actual specifications may vary depending on the gas type, valve configuration, and customer-specific requirements. Please refer to the final order confirmation and engineering drawings for exact compliance. Zhuzhou XingYe Chemical Co., Ltd operates under ISO 9001:2015 and holds CE, DOT SP, and TPED certifications as applicable. This content is for informational purposes and does not constitute a legally binding offer. Customers must verify local regulatory requirements before use.
